Bilstein Front B8 5100 (Ride Height Adjustable) Shock (24-300872) for 2019-2024 Cummins 6.7L

$223.60Purchase & earn 223 points!

The Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUVs with front OE coilover-style suspension. They feature multiple snap-ring grooves that allow adjustable spring seat positions, offering 0–3 inches of front lift using OE springs (depending on the vehicle). With a 46mm monotube design and self-adjusting valve, these shocks enhance wheel travel and handling. They provide an easy solution for leveling your vehicle.

5 People watching this product now!
Description

Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUVs with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0-3 inches of front lift with OE springs (depending on application). The monotube shock absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting.  Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.

Additional information
Weight 6 lbs
Dimensions 26.8 × 3.55 × 3.55 in
Fitment

Fitment

2019-2024 Cummins 6.7L

Features

Features

  • Adjustable Ride Height: Allows for manual adjustment of the vehicle’s ride height, you can keep it at stock height, raise it a little, level it out with the rear or go a little bit higher.
  • Monotube Design: Bilstein 5100 Ride Height Adjustable Struts feature the same monotube gas-pressure design that makes Bilstein the pioneer in Truck shock technology.
  • Eliminates Coil Spacers: No need for any outside lifts or spacers. Bilstein allows you to raise the truck without changing the technology of the OEM spring.
  • Adjustable Spring Perch: Will lift the vehicle up to 3 inches depending on the make, model, year.
  • Multiple Settings: Depending on the model, it offers different height settings, giving drivers flexibility in adjusting ground clearance and vehicle stance.

Benefits of the Bilstein 24-300872:

    Customizable Stance: Adjust the ride height to achieve the stance you want or to better suit your driving conditions.Save Money: No need to buy a lift kit. Reduce labor costs and get a superior product and ride.Enhanced Off-Road Capability and Bigger Tires: Higher ground clearance settings allow you to add a larger tire and give the truck more capability in off-road conditions.Increased Durability, Improved Handling and The Best in Ride Comfort: Bilstein’s monotube design and high-quality materials get you a strut that lasts longer than any other. You gain more stability and control during cornering, braking, and accelerating and the ride comfort is game changing.

%%ATTRIBUTES%%

Specifications

  • Adjustable Damping: Non-Adjustable
  • Body Design: Snap Ring Grooved Body (Coilover)
  • Body Diameter (ID): 46mm
  • Boot Included: No
  • Collapsed Length (IN): 16.00
  • Collapsed Length (MM): 406.5
  • Extended Length (IN): 22.08
  • Extended Length (MM): 560.9
  • Finish: Zinc Plated
  • Internal Design: Monotube
  • Lower Mount Type: Clevis
  • Reservoir: No
  • Spring Seat Included: Yes
  • Upper Mount Type: Stem
Installation

Installation

Installation Instructions

MSDS

Warranty

About brand
Bilstein builds shock absorbers for diesel trucks and performance vehicles. The company focuses on ride control, durability, and consistent handling. Bilstein shocks diesel suspension supports daily driving, towing, and work use. Bilstein designs shocks using gas-pressure technology for improved damping. These shocks help control body movement and maintain stability under load. Better control improves comfort and driver confidence. Truck owners trust the brand for dependable suspension upgrades. These shocks perform well in real-world driving conditions.
